0.87 “ Small Size 50 RGB×120 Dots TFT LCD Display Module Screen

Short Description:

Model No: SPEC N087-0512KTBIG41-H13

Size: 0.87 inch

Pixels: 50 x 120 Dots

A.A: 8.49 x 20.37 mm

Outline: 10.8 x 25.38 x 2.13 mm

View Direction: ALL REVIEW

Interface: 4 Line SPI

Brightness(cd/m²): 350

Driver IC: GC9D01

Touch Panel: Without Touch Panel

Send email to us Download as PDF

Product Detail

Product Tags

General Description

Display Type	IPS-TFT-LCD
Brand name	WISEVISION
Size	0.87 inch
Pixels	50 x 120 Dots
View Direction	ALL REVIEW
Active Area (A.A)	8.49 x 20.37mm
Panel Size	10.8 x 25.38 x 2.13mm
Color arrangement	RGB Vertical stripe
Color	65K
Brightness	350 (Min)cd/m²
Interface	4 Line SPI
Pin Number	13
Driver IC	GC9D01
Backlight Type	1 White LED
Voltage	2.5~3.3 V
Weight	1.1
Operational Temperature	-20 ~ +70 °C
Storage Temperature	-30 ~ +80°C

Product Information

N087-0512KTBIG41-H13 is a 0.87-inch IPS TFT-LCD with a resolution of 50x120 pixels. supports various interfaces such as SPI, providing flexibility for seamless integration into any project. The display's brightness of 350 cd/m² ensures clear, vivid visuals even in bright lighting conditions. The monitor uses the advanced GC9D01 driver IC to ensure smooth and efficient performance.
N087-0512KTBIG41-H13 adopts wide angle IPS (In plane Switching) technology. The viewing range is left: 70/right: 70/up: 70/down: 70 degrees. a contrast ratio of 1000:1, and an aspect ratio of 3:4 (typical value). The supply voltage for analog is from 2.5V to 3.3V (the typical value is 2.8V).The IPS panel has a wide range of viewing angles, bright colors, and high-quality images that are saturated and natural. This TFT-LCD module can work under temperatures from -20℃ to +70℃, and its storage temperatures range from -30℃ to +80℃.
