1.53 “ Small Size 360 RGB×360Dots TFT LCD Display Module Screen

Short Description:

N150-3636KTWIG01-C16 is a TFT-LCD Module with a 1.53-inch diagonal round screen and a resolution of 360*360 pixels. This round LCD screen adopts an QSPI panel, which has the advantages of higher contrast, a full black background when the display or pixel is off, and wider viewing angles of Left:80 / Right:80 / Up:80 / Down:80 degrees (typical), 1500:1 contrast ratio (typical value), 400 cd/m² brightness (typical value), and an anti-glare glass surface.

The module is built-in with ST77916 driver IC that can support via QSPI interfaces. The power supply voltage of LCM is from 2.4V to 3.3V, the typical value of 2.8V. The display module is suitable for compact devices, wearable devices, home automation products, white products, video systems, medical instruments, etc. It can be operating at temperatures from -20℃ to+ 70℃ and storage temperatures from -30℃ to +80℃.

Model No: : N150-3636KTWIG01-C16

Size: : 1.53 inch

Pixels: : 360RGB*360 Dots

A.A: : 38.16×38.16 mm

Outline: : 40.46×41.96×2.16 mm

View Direction: : ALL View

Interface:: QSPI

Brightness(cd/m²):: 400

Driver IC: : ST77916

Touch Panel: : Without Touch Panel

Send email to us Download as PDF

Product Detail

Product Tags

General Description

Display Type	IPS-TFT-LCD
Brand name	WISEVISION
Size	1.53 inch
Pixels	360×360 Dots
View Direction	All View
Active Area (A.A)	38.16×38.16 mm
Panel Size	40.46×41.96×2.16mm
Color arrangement	RGB Vertical stripe
Color	262K
Brightness	400 (Min)cd/m²
Interface	QSPI
Pin Number	16
Driver IC	ST77916
Backlight Type	3 CHIP-WHITE LED
Voltage	2.4~3.3 V
Weight	TBD
Operational Temperature	-20 ~ +70 °C
Storage Temperature	-30 ~ +80°C
