3.36 “ Small Size 240 RGB×320 Dots TFT LCD Display Module Screen

Short Description:


  • Model No: TFT035Y048-A0
  • Size: 3.36 inch
  • Pixels: 240×320 Dots
  • A.A: 51.27×68.36 mm
  • Outline: 54.5×83×2.2mm
  • View Direction: IPS/Free
  • Interface: MCU8BIT
  • Brightness(cd/m²): 250
  • Driver IC: ILI9340X
  • Touch Panel: Without Touch Panel
  • Product Detail

    Product Tags

    General Description

    Display Type IPS-TFT-LCD
    Brand name WISEVISION
    Size 3.36 inch
    Pixels 240×320 Dots
    View Direction IPS/Free
    Active Area (A.A) 51.27×68.36 mm
    Panel Size 54.5×83×2.2 mm
    Color arrangement RGB Vertical stripe
    Color 262K
    Brightness 250 (Min)cd/m²
    Interface MCU8BIT
    Pin Number 15
    Driver IC ILI9340X
    Backlight Type 6 CHIP-WHITE LED
    Voltage 2.7~3.3 V
    Weight TBD
    Operational Temperature -20 ~ +70 °C
    Storage Temperature -30 ~ +80°C

    Product Information

    TFT035Y048-A0 is a small-sized 3.36-inch IPS wide-angle TFT-LCD display module.

    This small-sized TFT-LCD panel has a resolution of 240×320 pixels, The display module is built-in with ILI9340X controller IC, supports MCU 8-bit or SPI interface, a supply voltage (VDD) range of 2.7V~3.3V, module brightness of 250 cd/m² (typical value), and contrast of 1200 (typical value).

    This 3.36 inches TFT- LCD display module is portrait mode, and the panel adopts wide angle IPS (In plane Switching) technology. The viewing range is left: 80/right: 80/up: 80/down: 80 degrees.

    The panel has a wide range of perspectives, bright colors, and high-quality images with saturated nature.

    It is very suitable for applications such as medical instruments, handheld devices, security monitoring system.

    The operating temperature of this module is -20 ℃ to 70 ℃, and the storage temperature is -30 ℃ to 80 ℃.

    Mechanical Drawing

    350-TFT5

    Product Introduction

    Introducing the remarkable and highly advanced 3.36" small size 240 RGB×320 dots TFT LCD display module screen! This cutting-edge display module is designed to revolutionize the display experiences of various electronic devices. With its compact size and exceptional performance, it offers endless possibilities for enhancing the visual output of your products.

    Featuring a high-resolution 240 RGB×320 dots display, this TFT LCD module produces stunningly vibrant and crisp images. Whether you are designing a mobile phone, smartwatch, embedded system, or any other portable device, this screen delivers exceptional visual clarity and detail rendering. Its small size makes it ideal for handheld devices, ensuring a comfortable and user-friendly experience while maintaining a compact form factor.

    The 3.36" TFT LCD display module boasts a wide viewing angle, allowing users to view the screen content from various angles without any loss in quality. This ensures that your product provides an immersive and engaging visual experience, enhancing the overall user satisfaction. The module also incorporates an advanced backlighting system, ensuring consistent and optimized brightness levels in different lighting conditions.

    This TFT LCD display module offers easy integration into your product design. It is equipped with a user-friendly interface, allowing for seamless connection with your device's mainboard and minimizing the development time. Additionally, it supports various input formats, enabling compatibility and versatility across different devices and applications.

    Furthermore, this display module is built to withstand the rigors of daily use. Its durable construction ensures resistance against scratches, impacts, and other external factors, guaranteeing a long lifespan and reliable performance.

    In conclusion, the 3.36" small size 240 RGB×320 dots TFT LCD display module screen is a game-changer in the world of electronic displays. Its exceptional resolution, wide viewing angle, and compact design make it an ideal choice for various devices and applications. Elevate your products to the next level with this remarkable display module and deliver an unparalleled visual experience to your users.
