4.30 “ Small Size 480 RGB×272 Dots TFT LCD Display Module Screen

Short Description:


  • Model No: TFT043B042
  • Size: 4.30 inch
  • Pixels: 480×272 Dots
  • A.A: 95.04×53.86 mm
  • Outline: 67.20×105.5×2.97 mm
  • View Direction: IPS/Free
  • Interface: RGB
  • Brightness(cd/m²): 350
  • Driver IC: NV3047
  • Touch Panel: Without Touch Panel
  • Product Detail

    Product Tags

    General Description

    Display Type IPS-TFT-LCD
    Brand name WISEVISION
    Size 4.30 inch
    Pixels 480×272 Dots
    View Direction IPS/Free
    Active Area (A.A) 95.04×53.86 mm
    Panel Size 67.20×105.5×2.97 mm
    Color arrangement RGB Vertical stripe
    Color 262K
    Brightness 350 (Min)cd/m²
    Interface RGB
    Pin Number 15
    Driver IC NV3047
    Backlight Type 7 CHIP-WHITE LED
    Voltage 3.0~3.6 V
    Weight TBD
    Operational Temperature -20 ~ +70 °C
    Storage Temperature -30 ~ +80°C

    Product Information

    TFT043B042 is a 4.3 inches IPS TFT-LCD with a wide viewing angle LCD display module, with a resolution of 480x272 full color screen, built-in NV3047 driver IC, and RGB 24bit interface support.

    This IPS TFT module has a brightness of 350 cd/m² (typical value), a screen aspect ratio of 16:9, a contrast of 1000 (typical value), and glossy glass.

    TFT043B042 adopts the IPS (In plane Switching) panel technology with the widest viewing angle, with a viewing range of left: 85/right: 85/top: 85/bottom: 85 degrees.

    The IPS panel has a wide viewing angle, bright colors, and high-quality images that are saturated and natural.

    The working temperature of the module is -20 ℃ to+70 ℃, and the storage temperature is -30 ℃ to+80 ℃.

    Mechanical Drawing

    430-TFT5
