NEW RELEASE
Wisevision, a leader in display, is proud to announce the launch of 1.53 “ Small Size 360 RGB×360Dots TFT LCD Display Module Screen”
Main specification
Model No: N150-3636KTWIG01-C16
Size: 1.53 inch
Pixels: 360RGB*360 Dots
A.A: 38.16×38.16 mm
Outline: 40.46×41.96×2.16 mm
View Direction: ALL View
Interface: QSPI
Brightness(cd/m²): 400
Driver IC: ST77916
Touch Panel: Without Touch Panel
More details:
N150-3636KTWIG01-C16 is a TFT-LCD Module with a 1.53-inch diagonal round screen and a resolution of 360*360 pixels. This round LCD screen adopts an QSPI panel, which has the advantages of higher contrast, a full black background when the display or pixel is off, and wider viewing angles of Left:80 / Right:80 / Up:80 / Down:80 degrees (typical), 1500:1 contrast ratio (typical value), 400 cd/m² brightness (typical value), and an anti-glare glass surface.
The module is built-in with ST77916 driver IC that can support via QSPI interfaces. The power supply voltage of LCM is from 2.4V to 3.3V, the typical value of 2.8V. The display module is suitable for compact devices, wearable devices, home automation products, white products, video systems, medical instruments, etc. It can be operating at temperatures from -20℃ to+ 70℃ and storage temperatures from -30℃ to +80℃.
General Description
| Display Type | IPS-TFT-LCD |
| Brand name | WISEVISION |
| Size | 1.53 inch |
| Pixels | 360×360 Dots |
| View Direction | All View |
| Active Area (A.A) | 38.16×38.16 mm |
| Panel Size | 40.46×41.96×2.16mm |
| Color arrangement | RGB Vertical stripe |
| Color | 262K |
| Brightness | 400 (Min)cd/m² |
| Interface | QSPI |
| Pin Number | 16 |
| Driver IC | ST77916 |
| Backlight Type | 3 CHIP-WHITE LED |
| Voltage | 2.4~3.3 V |
| Weight | TBD |
| Operational Temperature | -20 ~ +70 °C |
| Storage Temperature | -30 ~ +80°C |
Mechanical Drawing
Provide various display solutions, considerate after-sale services
Accept tooling, customization of FPC,backlight and size;
Specialize in technical support and design-in
Post time: Mar-24-2025
